Casyoo Quadra Series Solar/AC LED Post Top Area Light | IP65 Outdoor Fixture
$60.80
- Solar / AC Versions: One series, two power choices
- 30–80W Output: Stable outdoor brightness
- 30W Mono Solar Panel: Fast daytime charging (solar)
- 3.2V 20Ah Battery: Long overnight runtime (solar)
- MPPT + Photocell: Dusk-to-dawn automation
- Remote Control: Mode & timer selection (solar)
- IP65 Die-Cast Aluminum: Weatherproof durability
- Anti-Glare PC Shade: Uniform light, resists yellowing
- Expect your order to be delivered before scheduled dates
- 5-year warranty & 24h technical support
Description
Casyoo Quadra Series Solar/AC-Powered LED Post Top Area Light is designed to illuminate parks, courtyards, villa communities, sidewalks, and local streets with stable, comfortable lighting. It has a rugged die-cast aluminum body which is resistant to corrosion and high flame-retardant, thickened pc diffuser that helps to provide uniform transmission and helps in reducing glare and staying clearer for a longer time to avoid yellowing. Select solar or AC-powered options to suit your project. Solar models combine a 30W monocrystalline panel, 20Ah (3.2V) lithium battery, and MPPT controller to charge efficiently and provide reliable operation at dusk to dawn, with remote control to select mode and runtime. Quadra can be used throughout the year with an ability to produce a consistent output of 30-80W and can have a wide area coverage under minimum hands-on maintenance.
- Dual Power Supports – solar or AC powered, two power options under one series.
- Anti-Yellowing PC Diffuser – reduces the brightness and uniformly spreads the light for visual comfort. The thickened, flame-retardant PC helps maintain clarity over time.
- 30W Monocrystalline Solar + MPPT Control (Solar Model) – higher charging efficiency and more stable lighting at night, even in changing weather patterns.
- 3.2V 20Ah Lithium Battery Backup (Solar Model) – Long overnight operation supported, continuous output supported, dark hours minimized, seasonal performance change minimized.
- Remote + Photocell Control (Solar Model) – enables quick mode switching and timed operation without rewiring, adds automatic dusk-to-dawn operation, requires less manual operation.
- Wide and Practical Area Coverage – Lights approximately 20–30㎡ (solar) or 40–50㎡ (AC), increase visibility along the pathway in community and landscape settings.
- IP65 Die-Cast Aluminum Housing – ensures long service life as it is anti-corrosion and resistant to rain, dust and other outside factors.
Ideal For:
Parks, courtyards, villa communities, sidewalks and local streets
Specification
| Series | Willow Series |
| Versions | Solar Powered / AC Powered |
| Power Options (AC) | 30W–80W (Customizable) |
| LED Type | SMD3030 |
| LED Quantity | 120 pcs (Solar Version) / 120 pcs (AC Version) |
| Solar Panel (Solar Model) | 30W Monocrystalline / 6V |
| Battery (Solar Model) | 3.2V 20Ah Lithium Battery |
| Charging Time (Solar Model) | 5–6 hours |
| Control Method | Remote Control + Photocell (Solar Model) / AC Switching (AC Model) |
| Lighting Area | 20–30㎡ (Solar Model) / 40–50㎡ (AC Model) |
| CCT Options | Cool White / Warm White |
| Housing Material | Die-Cast Aluminum + PC Lampshade |
| Finish Color | Sand Black / Sand Gray |
| Ingress Protection | IP65 |
| Operating Temperature | -30°C to +50°C |
| Product Size (L×W×H) | 450×450×350 mm |
| Net Weight | 5.4 kg (Solar Model) / 4.4 kg (AC Model) |
| Pole Compatibility | 76 mm Pole (recommended) |
| LED Chip Brand Options | Osram / Others (Customizable) |
| Customization | OEM/ODM supported (configuration, branding, specification) |
FAQs
1. Please tell the difference between the Solar and AC versions.
Solar models have 30W monocrystalline panel, MPPT controller and a 3.2V 20Ah battery that can operate during dusk and dawn. AC models are connected to mains power and have 30-80W options with greater and more consistent area coverage.
2. Does PC diffuser actually prevent glare and yellowing?
Yes. The thickened and flame-retardant PC diffuser is designed to reduce direct glare, improve uniformity, and remain clearer even in outdoor environments compared to normal plastics.
3. What does MPPT do in the solar version?
MPPT will improve the light battery charging efficiency by optimizing the solar panel’s output. This can ensure more dependable performance at night.
4. What pole size is it fitted to and what mounting height do you support?
Quadra is normally combined with a pole of 76mm.Its recommended mounting heights are 3m/3.5m/4m, depending on the target area and spacing.
5. What customization is available for OEM/ODM orders?
Branding, housing color, LED/chip brand, CCT, control logic, packaging, and specification alignment for tenders or multi-site deployments.
6. What is the information required to quote the right configuration?
Please provide installation site, target lighting area, preferred power version (solar/AC), height of mounting, CCT and other project requirements (logo, packing, certification, tender requirements).
